TEXA IR CALIBRATION TARGET complete with night vision calibration column for MERCEDES

Description

TEXA IR Calibration Target with Night Vision Calibration Column ÔÇö Mercedes-Benz (S12612)

Designed exclusively for Mercedes-Benz vehicles fitted with infrared night vision camera systems, the TEXA S12612 is a complete IR calibration target assembly that integrates with the TEXA RCCS (Radar & Camera Calibration System) platform. Compatible with the RCCS 2, RCCS 3, and RCCS 3 EVO calibration frames, this assembly enables technicians to execute OEM-specified night vision camera calibrations following windshield replacement, camera removal and reinstallation, or any front-end repair that displaces the sensor from its factory position.

Unlike generic or multi-make targets, the S12612 is a vehicle-specific calibration panel built for one purpose: satisfying the Mercedes-Benz night vision calibration procedure. The kit combines the IR-reflective target panel with a dedicated night vision calibration column that mounts directly to the RCCS frame, positioning the target at the exact height and standoff distance required by the Mercedes-Benz OEM calibration specification.

What This Target Covers

• System: Mercedes-Benz night vision (infrared) front camera calibration
• Calibration type: Static ADAS calibration ÔÇö performed in a controlled indoor environment using the RCCS frame
• Compatible RCCS frames: TEXA RCCS 2, RCCS 3, RCCS 3 EVO (frame sold separately)
• Software required: TEXA IDC5 ADAS calibration software with active subscription (sold separately)
• Interface required: TEXA Navigator TXT or NANO diagnostic interface (sold separately)

What’s Included

• IR calibration target panel (Mercedes-Benz night vision specific)
• Night vision calibration column (mounts to RCCS frame crossbar)
• Hardware and mounting brackets for column-to-frame attachment

The night vision calibration column is the critical element of this assembly. Because IR targets must be raised to a precise height relative to the vehicle’s front bumper line, the column handles that positioning requirement directly ÔÇö no separate stand, no fabricated mounting solution, no improvisation required.

Who Needs This

This target is intended for shops that already operate a TEXA RCCS calibration frame and regularly service Mercedes-Benz vehicles with the night vision option. For any shop performing windshield replacements or front-end repairs on these vehicles, the S12612 is a required add-on ÔÇö the IDC5 software will specifically prompt for this target type and cannot advance through the night vision calibration sequence without it.

If your shop handles collision repair or ADAS recalibration on Mercedes-Benz and you have already encountered the night vision calibration step, you know that an off-brand IR target or a field-improvised solution will not fulfill the OEM procedure. The S12612 is the correct, purpose-built tool for that calibration.

If you have not yet invested in a TEXA RCCS frame, reach out to ADAS Calibration Tools ÔÇö we can build a complete system quote covering the frame, software, diagnostic interface, and the Mercedes-Benz target panels appropriate for your vehicle mix.

Calibration Workflow

• Step 1: Position vehicle on a flat, level surface using the RCCS self-centering laser alignment system
• Step 2: Mount the night vision calibration column to the RCCS frame crossbar at the correct lateral position
• Step 3: Attach the IR calibration target to the column at the specified height
• Step 4: Connect TEXA Navigator interface to vehicle OBD port; launch IDC5 ADAS module
• Step 5: Follow IDC5 on-screen procedure ÔÇö software guides the technician through the Mercedes-Benz OEM calibration sequence
• Step 6: Confirm calibration pass/fail in IDC5; print or save calibration report for the repair order

Technical Notes

• SKU: S12612
• Price: $1,819.00
• Compatible frames: TEXA RCCS 2, RCCS 3, RCCS 3 EVO
• Vehicle specificity: Mercedes-Benz only ÔÇö this is not a universal IR target
• Exact model-year coverage and standoff distance specifications are available on request ÔÇö contact us before ordering if you need to confirm compatibility with a specific Mercedes-Benz platform

Why Buy From ADAS Calibration Tools?

• Authorized TEXA dealer ÔÇö we stock RCCS targets, frames, and accessories and know the TEXA ADAS ecosystem in detail
• Free ground shipping on this order
• Free tech support at 800-123-4567 ÔÇö whether you have questions about RCCS frame compatibility, which additional Mercedes-Benz targets your shop needs, or how the IDC5 subscription works, our team has the answers
• Full manufacturer warranty on every TEXA product we sell
• Straightforward guidance ÔÇö if the S12612 is not the right fit for your vehicle mix, we will say so and point you toward the correct solution
