Autel MS909CV

Description

Autel MS909CV ÔÇö Commercial Vehicle Diagnostic Tablet

Built specifically for the commercial vehicle sector, the MS909CV is Autel’s dedicated diagnostic platform for shops that work across the full spectrum of commercial equipment. Whether your bays see half-ton pickups, Class 8 Freightliners, school buses, transit buses, coaches, or RVs, this is the tool engineered to handle that breadth. Rather than juggling multiple OEM tools or subscriptions, the MS909CV consolidates full diagnostics, bi-directional testing, and maintenance service functions into a single tablet ÔÇö covering domestic, European, and Asian light, medium, and heavy commercial vehicles.

This is not a passenger car tool with truck coverage added as an afterthought. The MS909CV was purpose-built for commercial vehicle workflows, with the coverage depth and diagnostic structure that reflects how CV shops actually operate day to day.

Hardware and Platform

• Processor: Octa-core CPU with 128GB onboard storage
• Operating system: Android 7.0
• Display: 9.7-inch touchscreen
• VCI: MaxiFlash VCI included ÔÇö connects to both light-duty and heavy-duty protocols

Diagnostic Coverage

• Vehicle range: F-150 through Freightliner ÔÇö light, medium, and heavy trucks, school buses, coaches, RVs, and transit buses
• Origins: Domestic, European, and Asian commercial vehicles
• Functions: Full system diagnostics, bi-directional active tests, and maintenance service functions across all supported platforms
• AutoSCAN / VINScan: Enhanced VIN-based vehicle identification and full-system scan with DTC analysis
• Module Topology: Visual system map showing which modules are communicating and which have faults ÔÇö available on select vehicles

Intelligent Diagnostics

• Repair Guided Assist: Step-by-step repair guidance tied to specific DTCs, sourced from experienced technicians and real-world cases
• DTC Analysis: Cross-references fault codes with known fixes and related technical service data
• Online repair information: Live access to repair cases and expert guidance during the diagnostic process

ADAS Calibration

• Class 3ÔÇô5 ADAS: Complete static and dynamic calibration coverage for medium-duty commercial vehicles
• Class 6ÔÇô8 Dynamic Calibration: Supported ÔÇö covers the radar, camera, and driver assistance systems on heavy commercial vehicles
• Class 6ÔÇô8 Static Calibration: Listed as coming soon at time of release ÔÇö confirm current status with us before purchasing if this function is critical to your workflow
• Calibration is required after any windshield replacement, front-end repair, or sensor R&R on ADAS-equipped commercial vehicles

Battery Testing

• Supports heavy-duty battery testing and generates a health report ÔÇö useful for fleet maintenance and pre-trip inspection workflows

What’s Included

• MS909CV diagnostic tablet
• MaxiFlash VCI module
• One year of Autel’s Total Care Program (TCP): software updates, technical support, and hardware warranty
• Standard charging and connection accessories

Who Needs the MS909CV

The MS909CV is the right fit for shops running a mixed fleet ÔÇö operations where the same bay handles pickups one hour and a medium or heavy truck the next. Fleet maintenance operations, commercial vehicle dealerships, and general repair shops in markets with significant agricultural or transportation equipment traffic will find the coverage depth here eliminates the need for multiple OEM tools or overlapping subscriptions.

If your operation is exclusively Class 6ÔÇô8 with zero light-duty crossover, reach out to us ÔÇö there may be a more specialized configuration worth exploring. And if your work is primarily light-duty passenger vehicles with only occasional commercial jobs, the standard MS909 is likely a better match at a lower price point.

Total Care Program ÔÇö Year One Included

Every MS909CV ships with one year of Autel’s Total Care Program, which covers software updates, access to Autel’s technical support team, and the manufacturer hardware warranty. Renewals are available once the first year expires. Staying current on software is particularly important in the commercial vehicle space ÔÇö OEM protocol changes and new model coverage are released on a rolling basis, and an outdated tool can quickly fall behind.
