Autel MaxiSYS MS909 S2 with ADAS Calibration Software

Description

Autel MS909 S2 with ADAS Calibration Software

The MS909 S2 with ADAS Calibration Software (SKU: MS909S2ADAS) represents the latest generation of the MS909 S2 diagnostic tablet, shipped with ADAS calibration software already activated. Designed for collision repair facilities and general service shops alike, this configuration delivers a unified platform for full-system diagnostics, pre/post-scan documentation, and guided ADAS recalibration ÔÇö all from a single tablet powered by Android 13, an octa-core 2.7 GHz processor, and the updated MaxiFLASH VCI2.

Important: The ADAS software activation unlocks calibration procedures directly on the tablet. Performing physical ADAS calibrations still requires a compatible target frame system (Autel IA700, IA900, IA900WA, or MA600). Frame and target kits are sold separately or available as part of bundled packages ÔÇö contact us to discuss the right configuration for your shop.

Who Needs This Configuration

The MS909S2ADAS is the right fit when:

• You already own ÔÇö or are purchasing separately ÔÇö an Autel ADAS frame and need the tablet with calibration software ready out of the box
• Your collision shop requires one device for both pre/post-scan documentation and ADAS recalibration procedures
• You are stepping up from an older Autel diagnostic tablet and want the current MS909 generation with ADAS capability built in
• You need the full MS909 S2 diagnostic platform and want ADAS software included rather than added later

If a complete solution ÔÇö frame, targets, and tablet together ÔÇö better suits your needs, ask us about our full ADAS system packages.

Full Diagnostic Capabilities (MS909 S2 Platform)

• Full OE-level system access ÔÇö all modules, all systems on 1996 and newer U.S., Asian, and European vehicles
• Bi-directional control ÔÇö actuator tests, component activation
• Coding and adaptations ÔÇö module programming, variant coding, OE-level adaptation functions
• 45+ service reset functions ÔÇö oil, EPB, SAS, BMS, DPF, IMMO, TPMS, and more
• All 10 OBDII test modes ÔÇö live data, freeze frame, Mode 6
• Pre- and post-scan reporting ÔÇö documented scan reports for insurance and customer records
• Topology 3.0 dynamic network analysis ÔÇö monitor individual module communications across multiple networks
• Enhanced Live Data ÔÇö Live Data Fusion, Reference Sampling, Parameter Graphing
• Security gateway access ÔÇö Mercedes-Benz, Nissan, VW/Audi, Stellantis authorized (AutoAuth account required)
• Remote Expert ready ÔÇö connect with remote programming experts
• MAX digital inspection app and hands-free navigation assistant built in
• MOTOR TruSpeed ÔÇö one year of free integrated repair data access

ADAS Calibration Capability

Once calibration software is activated, the MS909S2ADAS provides guided ADAS recalibration procedures for:

• Forward camera systems (LDW, FCW, AEB)
• Radar-based ACC systems
• Blind spot monitoring
• Rear camera systems
• 360-degree surround view systems (where applicable)

Compatible with Autel IA700, IA900, IA900WA, and MA600 frame systems.

Hardware Specifications

• OS: Android 13
• Processor: Octa-core, 2.7 GHz
• Memory: 12GB RAM / 256GB storage
• Display: 11″ anti-glare, 2176 x 1600
• Battery: 15,000mAh, USB-C 45W PD fast charging supported
• Weight: 1,656.5 g (3.65 lbs)
• Dimensions: 315.4 x 240.3 x 39.0 mm
• Connectivity: Wi-Fi 6.0 dual band, Bluetooth 5.2, GPS, 2x USB-A, USB-C, HDMI 2.0
• VCI: MaxiFLASH VCI2 with J2534 and CAN FD

Why Buy the MS909 S2 with ADAS Calibration Software from ADAS Calibration Tools?

ADAS Calibration Tools has specialized in professional diagnostic and ADAS calibration equipment. We go beyond simply selling hardware ÔÇö our focus is helping you select the right configuration for your shop’s specific workflow and vehicle mix. If you are weighing whether this tablet-only ADAS configuration is the right move or whether a bundled system makes more sense for your operation, call 800-123-4567 for a straightforward answer. Free shipping, the full manufacturer warranty, and no-pressure guidance come standard with every order.
